The AKM (Russian: Автомат Калашникова Модернизированный; Avtomat Kalashnikova Modernizirovanniy or "Kalashnikov modernized automatic rifle") is a 7.62mm assault rifle designed by Mikhail Kalashnikov. It is a common modernized variant of the AK-47 rifle developed in the 1940s.

Introduced into service with the Soviet Army in 1959, the AKM is the most ubiquitous variant of the entire AK series of firearms and it has found widespread use with most member states of the former Warsaw Pact and its many African and Asian allies as well as being widely exported and produced in many other countries. The production of these Soviet rifles was carried out at both the Tula Arms Plant and Izhmash. It was officially replaced in Soviet frontline service by the AK-74 in the late 1970s, but remains in use worldwide.

Design detailsEdit

Question book-new

This article does not contain any citations or references. Please improve this article by adding a reference. For information about how to add references, see Template:Citation.

The AKM is an assault rifle using the 7.62×39mm Soviet intermediate cartridge. It is gas operated with a rotating bolt. The AKM is capable of selective fire, firing either single shots or automatic at a cyclic rate of 600 rounds/min. Despite being replaced in the late 1970s by the AK-74 the AKM is still in service in some Russian Army reserve and second-line units and several east European countries.

Improvements over AK-47Edit

File:AKMS and M16 field stripped.jpeg

Compared to the AK-47, the AKM features detail improvements and enhancements that optimized the rifle for mass production; some parts and assemblies were conceived using simplified manufacturing methods. Notably, the AK-47's milled steel receiver was replaced by a U-shaped steel stamping. As a result of these modifications, the AKM’s weight was reduced by ≈ 1 kg (2.2 lb), the accuracy during automatic fire was increased and several reliability issues were addressed. The AK-47's chrome-lined barrel was retained, a common feature of Soviet weapons which resists wear and corrosion, particularly under harsh field conditions and near-universal Eastern Bloc use of corrosively primed ammunition.

The AKM’s receiver, compared to the AK-47, is stamped from a smooth 1.0 mm (0.04 in) sheet of steel. To the U-shaped stamped sheet metal receiver housing a rear stock trunnion and forward barrel trunnion are fastened using rivets. The receiver housing also features a rigid tubular cross-section support that adds structural strength. Guide rails that assist the bolt carrier’s movement which also incorporates the ejector are installed inside the receiver through spot welding. As a weight-saving measure, the stamped receiver cover is of thinner gauge metal than that of the AK-47. In order to maintain strength and durability it employs both longitudinal and latitudinal reinforcing ribs.

BarrelEdit

The forward barrel trunnion has a non-threaded socket for the barrel and a transverse hole for a pin that secures the barrel in place. On some models the rear trunnion has two extended mounting arms on both sides that support the buttstock; other fixed models use a stepped shaped trunnion that covers the full width of the inside of the receiver.

The AKM’s barrel is installed in the forward trunnion and pinned (as opposed to the AK-47, which has a one piece receiver with integral trunnions and a barrel that is screwed-in). Additionally the barrel has horizontal guide slots that help align and secure the handguards in place. To increase the weapon’s accuracy during automatic fire, the AKM was fitted with a slant cut muzzle brake that helps redirect expanding propellant gases upward and to the right during firing, which mitigates the rise of the muzzle during an automatic burst when held by a right-handed firer. The muzzle brake is threaded on to the end of the barrel with a left-hand thread. Not all AKMs had slant muzzle brakes; some were also fitted with the older muzzle nut which came from the AK-47. Most AKMs with muzzle nuts were older production weapons. The AKM's slant brake can also be used on the AK-47, which had a simple nut to cover the threads.

Gas blockEdit

The gas block in the AKM does not have a cleaning rod capture or sling loop but is instead fitted with an integrated bayonet support collar that has a cleaning rod guide hole. The forward sling loop was relocated to the front handguard retainer cap. The handguard retainer also has notches that determine the position of the handguards on the barrel. The AKM’s laminated wood handguards have lateral grooves that help securely grip the rifle.

Gas relief ports that alleviate gas pressure in the piston cylinder (placed horizontally in a row on the gas cylinder in the AK-47) were moved forward to the gas block and placed in a radial arrangement.

Bolt carrierEdit

The AKM’s bolt carrier is slightly lighter in weight and, despite some minor differences in its shape, it can be used interchangeably with the AK-47’s bolt carrier and bolt.

StockEdit

The buttstock, lower handguard and upper heatguard are manufactured from birch plywood laminates like the later model AK-47 furniture.[2] Such engineered woods are stronger and resist warping better than the conventional one-piece patterns, do not require lengthy maturing, and are cheaper. The wooden buttstock used in the AKM is further hollowed in order to reduce weight and is longer and straighter than that of the AK-47, which assists accuracy for subsequent shots during rapid and automatic fire. The wooden stock also houses the issued cleaning kit, which is a small diameter metal tube with a twist lock cap. The kit normally contains the cleaning jag to which a piece of cloth material is wrapped around and dipped into cleaning solution. It also contains a pin punch, an assembly pin to hold the trigger, disconnector and rate reducer together while putting these back into the receiver after cleaning the weapon, and a barrel brush. The kit is secured inside the butt stock via a spring-loaded trap door in the stock's pressed sheet metal butt cap.

SpringEdit

The AKM uses a modified return spring mechanism, which replaces the single recoil spring guide rod with a dual “U”-shaped wire guide.

Trigger assemblyEdit

The AKM has a modified trigger assembly, equipped with a hammer-release delaying device (installed on the same axis pin together with the trigger and disconnector) commonly called a "rate reducer". In fact its primary purpose is not to reduce the rate of automatic fire; it is a safety device to ensure the weapon will only fire on automatic when the bolt is fully locked, as the hammer is tripped by the bolt carrier's last few millimetres of forward movement. The device also reduces "trigger slap" or "trigger bounce" and the weapon’s rate of fire, which also reduces the dispersion of bullets when firing in fully automatic mode. The hammer was also changed and equipped with a protrusion that engages the rate reducer and the trigger has only one notched hammer release arm (compared to two parallel arms in the AK-47).[3][4]

SightsEdit

The AKM’s notched rear tangent iron sight is calibrated in 100 m (109 yd) increments from 100 to 1,000 m (109 to 1,094 yd) and compared to the AK-47 the leaf’s position teeth that secure the sliding adjustable notch were transferred over from the right to the left edge of the ramp. The front sight is a post adjustable for elevation in the field and has a slightly different shape and its bottom portion is more narrow compared to the AK-47. Horizontal adjustment requires a special drift tool and is done by the armory before issue or if the need arises by an armorer after issue. The "point-blank range" battle zero setting "П" on the 7.62×39mm AKM rear tangent sight element corresponds to a 300 m (328 yd) zero.[5] For the AKM combined with service cartridges the 300 m battle zero setting limits the apparent "bullet rise" within approximately −5 to +31 cm (−2.0 to 12.2 in) relative to the line of sight. Soldiers are instructed to fire at any target within this range by simply placing the sights on the center of mass (the belt buckle) of the enemy target. Any errors in range estimation are tactically irrelevant, as a well-aimed shot will hit the torso of the enemy soldier.[5]

MagazinesEdit

Bulgarian SOF prepares for Combined Resolve II (14041726380)

AKMS with a 30-round "bakelite" magazine. Despite their name, the magazines are actually made of fiberglass and resin along with steel reinforcements. The magazine has an "arrow in triangle" Izhmash arsenal mark on the bottom right.

The early slab-sided steel AK-47 30-round detachable box magazines weigh .43 kg (0.95 lb) empty.[6] The later steel AKM 30-round magazines had lighter sheet-metal bodies with prominent reinforcing ribs weighing .33 kilograms (0.73 lb) empty.[6][7] To further reduce weight a light weight magazine with an aluminum body weighing .19 kg (0.42 lb) empty was introduced for the AKM that proved to be insubstantial and was quickly withdrawn from service. As a replacement steel-reinforced 30-round plastic 7.62×39mm box magazines were introduced. These rust-colored magazines weigh .24 kg (0.53 lb) empty and are often mistakenly identified as being made of Bakelite (a phenolic resin), but were actually fabricated from two-parts of AG-S4 molding compound (a glass-reinforced phenol-formaldehyde binder impregnated composite), assembled using an epoxy resin adhesive.[8][9][10] Noted for their durability, these magazines did, however, compromise the rifle's camouflage and lacked the small horizontal reinforcing ribs running down both sides of the magazine body near the front that were added on all later plastic magazine generations.[10] A second generation steel-reinforced dark-brown (color shades vary from maroon to plum to near black) 30-round 7.62×39mm magazine was introduced in the early 1980s, fabricated from ABS plastic. The third generation steel-reinforced 30-round 7.62×39mm magazine is similar to the second generation, but is darker colored and has a matte nonreflective surface finish. The current issue steel-reinforced matte true black nonreflective surface finished 7.62×39mm 30-round magazines, fabricated from ABS plastic weigh .25 kg (0.55 lb) empty.[11] Early steel AK-47 magazines are 9.75 in (248 mm) long, and the later ribbed steel AKM and newer plastic 7.62×39mm magazines are about 1 in (25 mm) shorter.[12][13]

The transition from steel to mainly plastic magazines yielded a significant weight reduction and allow a soldier to carry more rounds for the same weight.

Rifle Cartridge Cartridge weight Weight of empty magazine Weight of loaded magazine Max. 10.12 kg (22.3 lb) ammunition load*
AK-47 (1949) 7.62×39mm 16.3 g (252 gr) slab-sided steel
430 g (0.95 lb)
30-rounds
916 g (2.019 lb)[14]
11 magazines for 330 rounds
10.12 kg (22.3 lb)
AKM (1957) 7.62×39mm 16.3 g (252 gr) ribbed stamped-steel
330 g (0.73 lb)
30-rounds
819 g (1.806 lb)[7][15]
12 magazines for 360 rounds
9.84 kg (21.7 lb)
AK-103 (1994) 7.62×39mm 16.3 g (252 gr) steel-reinforced plastic
250 g (0.55 lb)
30-rounds
739 g (1.629 lb)[7][15]
13 magazines for 390 rounds
9.62 kg (21.2 lb)

Note: All, 7.62×39mm AK magazines are backwards compatible with older AK variants.
Note *: 10.12 kg (22.3 lb) is the maximum amount of ammo that the average soldier can comfortably carry. It also allows for best comparison of the three most common 7.62×39mm AK platform magazines.

AccessoriesEdit

03 akm

6H4-type bayonet and scabbard

NVA AKM Bayonet (2 of 2)

AKM Type I bayonet of the Nationale Volksarmee that has cut an electrical wire

The AKM comes supplied with a different accessory kit that contains a M1959 6X4 or 6X3-type bayonet and comes with synthetic or steel magazines. The 6X3-type bayonet blade forms a wire-cutting device when coupled with its scabbard. The polymer grip and upper part of the scabbard provide insulation from the metal blade and bottom part of the metal scabbard, using a rubber insulator sleeve, to safely cut electrified wire. The kit also comes with a punch used to drive out various pins and a device that aids in assembling the rate reducing mechanism. The GP-25 Grenade launcher can also be fitted onto the AKM.

AmmunitionEdit

The weapon uses the same ammunition as the AK-47: the 7.62×39mm M43 intermediate rifle cartridge. The AKM mechanism's design principles and procedures for loading and firing are practically identical to those of the AK-47, the only difference being the trigger assembly (during the return stage of the bolt carrier on fully automatic mode) as a result of incorporating the rate reducer device.

VariantsEdit

AKMS - 7,62x39mm - Armémuseum

AKMS without magazine

AKML

AKML with NSP-3

AKMS vs AK-47

An AKMS (top) compared to a standard Soviet AK-47 (bottom).

Tishina automatic grenade launcher

AKMS with sound suppressor and silent BS-1 Tishina grenade launcher attached.

The main variant of the AKM is the AKMS (S – Skladnoy – Folding), which was equipped with an under-folding metal shoulder stock in place of the fixed wooden stock. The metal stock of the AKMS is somewhat different from the folding stock of the previous AKS-47 model as it has a modified locking mechanism, which locks both support arms of the AKMS stock instead of just one (left arm) as in the AKS-47 folding model. It is also made of riveted steel pressings, instead of the milled versions of most AKS-47s.

The AKM was produced in the following versions: AKMP, AKML and AKMLP, whereas the AKMS led to the following models – AKMSP, AKMSN and AKMSNP. It is designed especially for use by paratroopers–as the folding stock permits more space for other equipment when jumping from a plane and then landing.

The AKMP rifle uses subdued Radium-illuminated aiming points integrated into the front and rear sight. These sights enable targets to be engaged in low-light conditions, e.g. when the battlefield is illuminated with flares, fires or muzzle flashes or when the target is visible as a shadow against an illuminated background. The sliding notch on the sight arm is then moved to the “S” setting (which corresponds to the “3” setting in the AKM). The sight itself is guided on the sliding scale and has a socket, which contains a tritium gas-filled capsule directly beneath the day-time notch. The tritium front post installs into the front sight base using a detent and spring.

The AKML comes equipped with a side-rail used to attach a night vision device. The mount comprises a flat plate riveted to the left wall of the receiver housing and a support bracket fixed to the mounting base with screws. To shield the light-sensitive photo detector plate of the night vision sight, the weapon uses a slotted flash suppressor, which replaces the standard recoil compensator. The AKML can also be deployed in the prone position with a detachable barrel-mounted bipod that helps stabilize the weapon and reduces operator fatigue during prolonged periods of observation. The bipod is supplied as an accessory and is carried in a holster attached to the duty belt.

The AKMN comes equipped with a side-rail used to attach a night vision device. The model designated AKMN-1 can thus mount the multi-model night vision scope 1PN51[16] and the AKMN2 the multi-model night vision scope 1PN58.[17]

The AKMLP is a version of the AKML with tritium sights (as in the AKMP).

The AKMSP rifle is based on the folding stock AKMS variant but fitted with tritium night sights, as in the AKMP.

The AKMSN model is derived from the AKMS and features an accessory rail used to mount a night vision sensor as seen on the AKML and additionally a flash hider and bipod. The left arm of the AKMSN’s folding stock is bent outwards in order to avoid the sight mount bracket during folding and the sling loop was moved further to the rear. Similarly to the AKMN-1, the AKMSN-1 can mount the multi-model night vision scope 1PN51[16] and the AKMSN2 the multi-model night vision scope 1PN58.[17]

A version of the AKMSN additionally supplied with factory tritium night sights is called the AKMSNP.

A version of the AKM with a modified lower handguard designed to accept the 40 mm wz. 1974 Pallad grenade launcher was developed in Poland and designated the karabinek-granatnik wz. 1974.

Users and local versionsEdit

The following countries and combatants use the AKM, unless information is provided on a local version that is used alongside it or instead:

DF-SD-03-04442

Egyptian soldiers in training with Egyptian-made Misr rifles.

Polish AKMS

A Kbk AKMS fitted with a MILES laser training device in the hands of a Polish soldier in 1997.

Romanian AKM Soldier

A Romanian sub-officer with a PM md. 65

AKM and MP5K

Foreground: A member of the United States Air Force field-qualifying with a USSR AKM in Iraq.

LCpl Cheema on the AK-47

U.S. Marine firing an East German MpiKMS-72 assault rifle.

  • Flag of Afghanistan.svg Afghanistan[18]
  • Flag of Albania.svg Albania[19]
  • Flag of Algeria.svg Algeria[19]
  • Flag of Angola.svg Angola[19]
  • Flag of Armenia.svg Armenia[19]
  • Flag of Azerbaijan.svg Azerbaijan[19]
  • Flag of Bangladesh.svg Bangladesh[19]
  • Flag of Belarus.svg Belarus[19]
  • Flag of Benin.svg Benin[19]
  • Flag of Bosnia and Herzegovina.svg Bosnia-Herzegovina[19]
  • Flag of Botswana.svg Botswana[19]
  • Flag of Bulgaria.svg Bulgaria: Produced locally.[19][20]
  • Flag of Cambodia.svg Cambodia[19]
  • Flag of Cape Verde.svg Cape Verde[19]
  • Flag of the Central African Republic.svg Central African Republic[19]
  • Flag of Chad.svg Chad[19]
  • Flag of Chile.svg Chile[21]
  • Flag of the Comoros.svg Comoros[19]
  • Flag of the Republic of the Congo.svg Congo-Brazzaville[19]
  • Flag of Cuba.svg Cuba: Produced locally under license.[19]
  • Flag of the Democratic Republic of the Congo.svg Democratic Republic of the Congo[19]
  • Flag of Djibouti.svg Djibouti[18]
  • Flag of East Germany.svg East Germany: Produced locally. Examples include the MPi-KM (fixed stock) and MPi-KMS-72 (side-folding stock)[22]
  • Flag of Egypt.svg Egypt: The Misr is an Egyptian copy of the AKM, manufactured by Factory 54 of the Maadi Company for Engineering Industries in Cairo for the Egyptian Army and for export sales.[23][24][25][26][27]
  • Flag of Equatorial Guinea.svg Equatorial Guinea[19]
  • Flag of Ethiopia.svg Ethiopia[18]
  • Flag of El Salvador.svg El Salvador[citation needed]
  • Flag of Eritrea.svg Eritrea[19]
  • Flag of Estonia.svg Estonia: Still in limited military/police use. Replaced by AK-74.[19]
  • Flag of Finland.svg Finland: Holds stocks of imported AKM clones for wartime reserve service (the Chinese Type 56 known as the RK 56 TP and the East German MPi-KM as the RK 72[28]) along with locally designed AK derivatives (the Rk 62 and the Rk 95 TP).
  • Flag of Gabon.svg Gabon[19]
  • Flag of Georgia.svg Georgia[19]
  • Flag of Guinea.svg Guinea[19]
  • Flag of Guinea-Bissau.svg Guinea-Bissau[19]
  • Flag of Guyana.svg Guyana[19]
  • Flag of Hungary.svg Hungary:[19] There is a Hungarian copy of the AKM called 'AK-63' manufactured by FÉG. The AK-63 comes with a fixed wooden or plastic stock, but there is a version with an under-folding metal stock called AK-63D.
  • Flag of India.svg India[19] Various models of AKM and AKM style rifle in use. A local variant developed and manufactured by the Rifle Factory Ishapore.
  • Flag of Iran.svg Iran[19] from Chinese manufactures
  • Flag of Iraq.svg Iraq[19] from Soviet and Romanian manufactures
  • Flag of Israel.svg Israel:[19] Captured from Arab armies over the course of the Arab-Israeli Conflict.
  • Flag of Kazakhstan.svg Kazakhstan[19]
  • Flag of Kurdistan.svg Kurdistan
  • Flag of Kyrgyzstan.svg Kyrgyzstan[18]
  • Flag of Laos.svg Laos[19]
  • Flag of Latvia.svg Latvia[19]
  • Flag of Lesotho.svg Lesotho[19]
  • Flag of Liberia.svg Liberia[19]
  • Flag of Libya.svg Libya[19]
  • Flag of Lithuania.svg Lithuania[19]
  • Flag of Madagascar.svg Madagascar[19]
  • Flag of Mali.svg Mali[19]Armed and Security Forces of Mali
  • Flag of Moldova.svg Moldova[19]
  • Flag of Mongolia.svg Mongolia[19]
  • Flag of Morocco.svg Morocco[19]
  • Flag of Mozambique.svg Mozambique[19]
  • Flag of Nicaragua.svg Nicaragua[citation needed]
  • Flag of North Korea.svg North Korea: Type 68 variant.[19] The variant does not have a rate reducer.[29]
  • Flag of Oman.svg Oman: Some captured from Dhofari rebels.[30]
  • Flag of Pakistan.svg Pakistan: Type 56 variant.[19]
  • Flag of Palestine.svg Palestinian Authority: M70 variant[31]
  • Flag of Peru.svg Peru[19]
  • Flag of the People's Republic of China.svg People's Republic of China: Type 56 variant.[18]
  • Flag of Poland.svg Poland: Produced locally. Replaced by Kbs wz. 1996 Beryl and soon by MSBS.[20][22]
  • Flag of Qatar.svg Qatar[19]
  • Flag of Macedonia.svg Republic of Macedonia[19]
  • Flag of Romania.svg Romania: Produced locally as the PM md. 63.[19][20]
  • Flag of Russia.svg Russia:[19] Still in limited military and police use. Officially replaced in most Russian military units by the AK-74. Some usage mainly in urban environments due to the ability to penetrate heavy cover.
  • Flag of Sao Tome and Principe.svg São Tomé and Príncipe[19]
  • Flag of Saudi Arabia.svg Saudi Arabia[32]
  • Flag of Serbia.svg Serbia[19]
  • Flag of Seychelles.svg Seychelles[19]
  • Flag of South Sudan.svg South Sudan[18]
  • Flag of Sierra Leone.svg Sierra Leone[19]
  • Flag of Slovenia.svg Slovenia[19]
  • Flag of Somalia.svg Somalia[19]
  • Flag of the Soviet Union.svg Soviet Union[18]
  • Flag of Sudan.svg Sudan[19]
  • Flag of Suriname.svg Suriname[19]
  • Flag of Sweden.svg Sweden A small number of AKM's are used by the Swedish Armed Forces for familiarization training,[33] but they are not issued to combat units.
  • Flag of Syria.svg Syria[19]
  • Flag of Tajikistan.svg Tajikistan[19]
  • Flag of Tanzania.svg Tanzania[19]
  • Flag of Togo.svg Togo[19]
  • Flag of Turkey.svg Turkey[19][34]
  • Flag of Turkmenistan.svg Turkmenistan[19]
  • Flag of Ukraine.svg Ukraine[19] still in limited use, officially replaced in most Ukrainian military units by the AK-74. AKMS used by Ukrainian Security Service
  • Flag of the United Arab Emirates.svg United Arab Emirates[19]
  • United States, captured rifles were used in Vietnam[35] and other conflicts.[36]
  • Flag of Uzbekistan.svg Uzbekistan[19]
  • Flag of Venezuela.svg Venezuela Purchased in 2005 [37]
  • Flag of Vietnam.svg Vietnam[19] Standard infantry rifle of the Vietnamese Army.
    • Flag of South Vietnam.svg South Vietnam, the ARVN were supplied with captured AKM rifles.[35]
  • Flag of Yemen.svg Yemen[19]
  • Flag of SFR Yugoslavia.svg Yugoslavia: Several variants based on the AKM built by Zastava Arms factory, most notably the M70 and M70B.[38]
  • Flag of Zambia.svg Zambia[19]
  • Flag of Zimbabwe.svg Zimbabwe[19]

See alsoEdit

ReferencesEdit

  1. 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 http://web.archive.org/web/20110718231355/http://www.izhmash.ru/eng/product/akm.shtml AKM (AK-47) Kalashnikov modernized assault rifle, caliber 7.62mm
  2. Comparing the Type 2 and Type 3 Russian AK-47 receivers
  3. Poyer 2006, pp. 8–11.
  4. Edward Ezell (1 March 1986). The AK47 story: evolution of the Kalashnikov weapons. Stackpole Books. p. 36. ISBN 978-0-8117-0916-3. https://books.google.com/books?id=LsYqAQAAMAAJ.
  5. 5.0 5.1 Gordon Rottman (24 May 2011). The AK-47: Kalashnikov-series Assault Rifles. Osprey Publishing. pp. 42–. ISBN 978-1-84908-835-0. https://books.google.com/books?id=qK9Nn-2xocUC&pg=PA42. Retrieved 24 December 2011.
  6. 6.0 6.1 Dockery, Kevin (2007). Future Weapons. p. 102. ISBN 0425217507.
  7. 7.0 7.1 7.2 "Ak 47 Technical Description - Manual". Scribd.com. 2010-09-30. http://www.scribd.com/doc/38483061/Ak-47-Technical-Description-Manual. Retrieved 2012-08-23.
  8. "Kalashnikovs 3 of the best". "Shotgun News" magazine, Vol. 59 Issue no. 12 - May, 2005. http://www.arsenalinc.com/usa/imgs/articles/BulgarianAK.pdf. Retrieved 10 April 2015.
  9. "Elastic characteristics of AG-4S glass-reinforced plastic under short-time and long-time loads". VM Grezin - Mechanics of Composite Materials, 1966 - Springer. http://link.springer.com/article/10.1007%2FBF00867112?LI=true#page-1. Retrieved 10 April 2015.
  10. 10.0 10.1 Kokalis, 49
  11. "фициальный сайт группы предприятий "ИЖМАШ"". http://www.izhmash.ru/eng/product/akm.shtml. Retrieved 2 October 2014.
  12. Rifle Evaluation Study, United States Army, Combat Development Command, ADA046961, 20 Dec 1962
  13. "Are kalashnikov magazines as robust as their reputation? He tormented a selection of AR magazines last year, now he takes on the AK. The results you may find surprising.". http://www.thefreelibrary.com/Are+kalashnikov+magazines+as+robust+as+their+reputation%3F+He+tormented...-a0262692779. Retrieved 2 October 2014.
  14. Dockery, Kevin (2007). Future Weapons. p. 102. ISBN 0-425-21750-7.
  15. 15.0 15.1 Dockery, Kevin (2007). Future Weapons. p. 102.
  16. 16.0 16.1 (in Russian) ИЗДЕЛИЕ 1ПН51 ТЕХНИЧЕСКОЕ ОПИСАНИЕ И ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ [PRODUCT 1PN51 TECHNICAL DESCRIPTION AND OPERATING INSTRUCTIONS]. January 1992. pp. 11, 16.
  17. 17.0 17.1 (in Russian) ИЗДЕЛИЕ 1ПН58 ТЕХНИЧЕСКОЕ ОПИСАНИЕ И ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ [PRODUCT 1PN58 TECHNICAL DESCRIPTION AND OPERATING INSTRUCTIONS]. February 1991. pp. 5, 12–13.
  18. 18.0 18.1 18.2 18.3 18.4 18.5 18.6 Rottman, Gordon (2011). The AK-47 Kalashnikov series assault rifles. Great Britain: Osprey Publishing. ISBN 978-1-84908-461-1.
  19. 19.00 19.01 19.02 19.03 19.04 19.05 19.06 19.07 19.08 19.09 19.10 19.11 19.12 19.13 19.14 19.15 19.16 19.17 19.18 19.19 19.20 19.21 19.22 19.23 19.24 19.25 19.26 19.27 19.28 19.29 19.30 19.31 19.32 19.33 19.34 19.35 19.36 19.37 19.38 19.39 19.40 19.41 19.42 19.43 19.44 19.45 19.46 19.47 19.48 19.49 19.50 19.51 19.52 19.53 19.54 19.55 19.56 19.57 19.58 19.59 19.60 19.61 19.62 19.63 19.64 19.65 19.66 19.67 19.68 19.69 19.70 19.71 19.72 Jones, Richard D. Jane's Infantry Weapons 2009/2010. Jane's Information Group; 35 edition (January 27, 2009). ISBN 978-0-7106-2869-5.
  20. 20.0 20.1 20.2 Personal infantry weapons: old weapons or new hardware in the coming decades? – Free Online Library. Thefreelibrary.com. Retrieved on 2014-04-20.
  21. Gander, Terry J.; Hogg, Ian V. Jane's Infantry Weapons 1995/1996. Jane's Information Group; 21 edition (May 1995). ISBN 978-0-7106-1241-0.
  22. 22.0 22.1 Modern Firearms – AK-47 AKM. World.guns.ru. Retrieved on 2014-04-20.
  23. "Maadi Company for Engineering Industries (Factory 54) Special Weapons Facilities – Egypt". Fas.org. https://fas.org/nuke/guide/egypt/facility/maadi-54.htm. Retrieved 2009-11-20.
  24. John Pike (2005-04-27). "Maadi Company for Engineering Industries (Factory 54)". Globalsecurity.org. http://www.globalsecurity.org/military/world/egypt/maadi-54.htm. Retrieved 2009-11-20.
  25. "Exhibits Page 16". Avtomats-in-action.com. Archived from the original on 25 December 2009. https://web.archive.org/web/20091225210916/http://www.avtomats-in-action.com/pro16.html. Retrieved 2009-11-20.
  26. Jeff Freeman. "Egyptian Rifles". Home.comcast.net. http://home.comcast.net/~jfreeman16/page_4.htm. Retrieved 2009-11-20.
  27. "Search the Small Arms Survey Website and Resources [Results for Misr"]. Geneva, Switzerland: Graduate Institute of International and Development Studies. http://www.smallarmssurvey.org/index.php?id=68&q%3D=misr. Retrieved 17 June 2014.
  28. "Puolustusvoimat: Kalustoesittely". Mil.fi. 2009-05-20. http://www.mil.fi/maavoimat/kalustoesittely/index.dsp?level=63&equipment=39. Retrieved 2009-11-20.
  29. US Department of Defense, North Korea Country Handbook 1997, Appendix A: Equipment Recognition, TYPE-68 (AKM) ASSAULT RIFLE, p. A-77
  30. McNab, Chris (2002). 20th Century Military Uniforms (2nd ed.). Kent: Grange Books. ISBN 1-84013-476-3.
  31. Palestinian security men, Hamas gunmen killed in West Bank clashes_English_Xinhua. News.xinhuanet.com (2009-05-31). Retrieved on 2014-04-20.
  32. Find Imagery. DefenseImagery.mil. Retrieved on 2014-04-20.
  33. M16 M16a2 Kalashnikov Ak-47 – Utländska Vapensatsen. SoldF.com. Retrieved on 2014-04-20.
  34. "Kalashnikov AKM". http://www.militaryfactory.com/smallarms/detail.asp?smallarms_id=180. Retrieved 4 June 2014.
  35. 35.0 35.1 Col. Michael Lee Lanning (1988). Inside the LRRPs: Rangers in Vietnam. Presidio Press. ISBN 0804101663.
  36. Walter J. Boyne (2003). Operation Iraqi Freedom: What Went Right, What Went Wrong, and Why. p. 110. ISBN 0765310384.
  37. http://www.globalsecurity.org/military/world/venezuela/army.htm
  38. "Automatic Weapon Family – cal. 7.62x39mm". Zastava-arms.co.rs. Archived from the original on June 24, 2009. https://web.archive.org/web/20090624030012/http://www.zastava-arms.co.rs/images/vojni/7_62/762_engleski.htm.

External linksEdit

This page uses Creative Commons Licensed content from Wikipedia (view authors).

Ad blocker interference detected!


Wikia is a free-to-use site that makes money from advertising. We have a modified experience for viewers using ad blockers

Wikia is not accessible if you’ve made further modifications. Remove the custom ad blocker rule(s) and the page will load as expected.
